6300 Series - Sunshade

The 6300 Series Sunshade System is an extension of our louver platform, designed to provide horizontal solar control and architectural shading. Installed above or across window openings, it enhances both energy performance and visual appeal. Fully customizable, it accommodates a variety of design preferences and structural supports.

System Features:

Blade Styles: Z-blade or airfoil blade options

End Detail Option: 3" (76.2 mm) diameter round tube accent

Mounting Options:

Metro’s 3" x 3/16" (76.2 mm x 4.8 mm) flat bar support

Compatible with steel outriggers by others

Projection: Designed to mount horizontally from window or curtain wall frames

Customization: Fully customizable sizing, blade spacing, and layout

Material Strength: T6-temper aluminum for durability

Finishes: Clear anodized, bronze anodized, black anodized, with custom anodizing and paint options available

Applications: Ideal for commercial or institutional buildings seeking reduced solar gain, architectural depth, and visual character
