Metro Aluminum

1100T Series Slider

Sliders
Thermally Broken
Yes
Glazing Type
Double
U-Value
Dimensions

The 1100T Series is a high-performance, thermally broken sliding door system designed for exterior applications where superior energy efficiency is required. It features a double poured thermal pocket and is available exclusively in double-glazed configurations. Built for durability and smooth operation, it’s ideal for residential or commercial use in demanding environments.

System Features:

Application: Exterior use

Glazing: Double glazed (15/16" overall thickness)

Thermal Performance: Double poured thermal pocket for maximum insulation

Configuration: Thermally broken patio-style sliding frame

Material Strength: T6-temper aluminum for structural integrity

Mid-Rail Option: Available for added design flexibility

Finishes: Clear anodized, bronze anodized, black anodized, with custom anodizing and paint options available

Sizing: Customizable sizes to suit project-specific requirements

Hardware: Compatible with a range of sliding and locking hardware

Screens: Optional screen systems available

Design Flexibility: Ideal for energy-conscious residential and commercial applications requiring thermal efficiency, durability, and clean aesthetics

Resources

PDF File

1100T Series Thermally Broken Slider.pdf

3.52 KB

Download
DWG File

1100T Series Thermally Broken Monumental Slider.dwg

1.84 KB

Download
